HTTP response schema validation

mnml validates HTTP response bodies against JSON Schema sidecars dropped next to the request file. Park a users.schema.json beside users.curl, fire the request, and the Response view paints a one-line footer — ✓ Schema valid (users.schema.json) or ✗ Schema: 3 errors (users.schema.json) — :http.show_schema_errors. The full validator output is one ex-command away.

The point is contract-driven debugging. When a downstream change quietly drops a field, the assertion arc (@assert json $.foo) needs you to remember every field. Schema validation needs the schema — which you already wrote, or generated from the API spec — and surfaces every drift at once.

The sidecar pattern

For a request file at <path>/<name>.<ext>, mnml resolves a sibling schema:

1. <path>/<name>.schema.json — preferred. For requests/users.curl, that’s requests/users.schema.json.
2. <path>/<name>.<ext>.schema.json — fallback. For requests/users.curl, requests/users.curl.schema.json.

The first form is the recommended layout: it reads cleanly next to the source, and it stays meaningful if you migrate the request file’s extension (.curl → .http). The two-suffix form exists for files like users.http where stripping the extension leaves you with a less identifiable stem.

requests/
  users.curl                ← the request
  users.schema.json         ← preferred sidecar location

requests/
  users.http                ← the request
  users.http.schema.json    ← fallback location (also accepted)

A single schema per source file in v1. Per-block schemas for multi-block .http files (users.<block>.schema.json) are queued as a v2 follow-up.

What the schema looks like

Plain JSON Schema (draft-07 onward — mnml uses the jsonschema crate’s auto-detected validator).

{
  "$schema": "https://json-schema.org/draft/2020-12/schema",
  "type": "object",
  "required": ["id", "name", "email"],
  "properties": {
    "id":    { "type": "integer", "minimum": 1 },
    "name":  { "type": "string",  "minLength": 1 },
    "email": { "type": "string",  "format": "email" },
    "role":  { "type": "string",  "enum": ["admin", "member", "viewer"] }
  },
  "additionalProperties": false
}

Hand-write them, or generate from your OpenAPI spec — mnml discover SPEC doesn’t emit schemas yet, but the operation’s response schema is sitting right there in the spec for you to copy across.

When validation runs

Every successful :http.send triggers validation. The flow:

1. The HTTP worker returns a ResponseView (status + headers + body).
2. crate::http::schema::validate_for(source_path, body) resolves the sidecar and runs the validator.
3. The result lands on ResponseView.schema_result — a SchemaResult carrying status + errors + the schema path.
4. The Response view’s footer line reads schema_result and renders one of six states.

No sidecar = no footer. No noise — schema validation only surfaces when you’ve opted in by dropping a schema file.

Validation also runs against :http.send_streaming responses (the streaming worker validates the accumulated body once the stream completes). It doesn’t run against :http.replay_mock or :http.bench runs — replay is a UI flip, not a real send; bench results don’t materialise per-shot bodies.

The footer states

The Response view paints exactly one of six footer states:

State	Footer	Colour
Valid	✓ Schema valid (users.schema.json)	green, bold
Invalid	✗ Schema: 3 errors (users.schema.json) — :http.show_schema_errors	red, bold
NoSidecar	(no footer)	—
ReadError	⚠ Schema read error (users.schema.json): <err>	yellow
SchemaParseError	⚠ Schema parse error (users.schema.json): <err>	yellow
NotJson	⚠ Body isn't JSON — schema (users.schema.json) skipped	yellow

Each error case shows up distinctly so the failure mode is obvious from the response without opening another buffer:

• NotJson — the response body wasn’t parseable JSON. A schema that expects an application/json body but the server returned HTML / plain text / an empty 204. Silent pass-through is the wrong move (the schema was meant to apply); the warning makes it visible.
• ReadError — the sidecar file exists but read_to_string failed (permissions, mid-write truncation, weird filesystem). Rare but distinguishable from a malformed schema.
• SchemaParseError — the sidecar is there and readable but isn’t a valid JSON Schema document. Surfaced verbatim from serde_json or jsonschema::validator_for. Edit the schema, then :http.revalidate_schema (below) to re-run without re-firing the request.

:http.show_schema_errors

When the footer reads ✗ Schema: N errors, this command opens a [schema-errors] scratch buffer listing every validator error.

Surface	Call
Palette	HTTP: open scratch buffer with response schema validation errors
Ex-command	:http.show_schema_errors

The scratch contents:

✗ Schema validation failed (/path/to/requests/users.schema.json)
  3 error(s):

    1. /email: "alice@" is not a "email"
    2. /role: "owner" is not one of ["admin", "member", "viewer"]
    3. /id: 0 is less than the minimum of 1

Each entry starts with the JSON Pointer into the response body where validation failed — /email, /role, /data/0/id. mnml prefixes the path so a screenful of errors scans cleanly; jsonschema’s own message ("alice@" is not a "email") follows after the colon.

The errors are emitted in the validator’s iteration order, which is roughly schema-walk order. For deeply nested schemas this means you read failures from the outermost property inward.

Edge-case toasts

This command short-circuits to a toast — no scratch — when the response wasn’t an Invalid schema result:

• schema: no sidecar (.schema.json) for this request — never had a sidecar; nothing to show.
• ✓ schema valid (path/to/schema.json) — the response passed; nothing to show, but you get a confirmation.
• schema: no completed response — fired before the response landed (or after a transport error). Wait for Done.

The ReadError / SchemaParseError / NotJson states each open a single-line scratch with the matching message, so you can copy-paste the path into a shell and inspect the schema yourself.

:http.revalidate_schema

Edit the sidecar .schema.json and want to re-test the existing response body? That’s :http.revalidate_schema — no re-fire needed.

Surface	Call
Palette	HTTP: re-run schema validation on the active Request pane's last response
Ex-command	:http.revalidate_schema

The flow:

1. Reads the response body and source path off the active Pane::Request.
2. Calls validate_for(source_path, body) — the same code path the original send took.
3. Writes the fresh SchemaResult onto the response.
4. Toasts the new state — ✓ schema re-validated: valid, ✗ schema re-validated: 3 error(s), etc.

The Response footer re-paints on the next frame.

Use it when:

• You’re iterating on the schema itself — tightening a required list, adding a format, narrowing an enum. Edit, save, :http.revalidate_schema, repeat.
• The original response was NotJson because you forgot the Accept: application/json header; re-fire normally instead.
• The original response was NoSidecar and you just dropped the schema file. (:http.revalidate_schema picks it up.)

A re-fire (r from Response view) revalidates implicitly — every successful send runs validation. :http.revalidate_schema is the schema-only path when the network call is expensive or non-idempotent.

Workflow

The natural rhythm:

1. Drop a schema next to the request. Generated from the OpenAPI spec, hand-written from a .mock.json you saved last week, or sketched against a working response body.
2. Fire the request. The footer says ✓ Schema valid (file) or ✗ Schema: N errors (file).
3. Drill in. If errors, :http.show_schema_errors opens the full list.
4. Iterate. Either fix the API / the request, or tighten the schema. After a schema edit, :http.revalidate_schema re-checks against the in-pane response.

Pairing with @assert

Schema validation and @assert directives stack — they validate at different levels:

• @assert — surgical, one-off checks. status == 200, header.Content-Type contains json, json $.data[0].id is number. Inline in the request file, ergonomic for the rare “this specific value must be X” check.
• Schema — structural. Every field that ever ships on this endpoint’s success response, all at once. Lives in a separate file so the structure is reusable across requests (one user.schema.json referenced from every request that returns a user).

Use them together: an @assert status == 200 plus a schema validates the success-path body shape without typing out a @assert json for every leaf field.

Adding to .gitignore?

No. Commit .schema.json files. They’re contracts, not secrets. Treat them like the OpenAPI spec they probably came from.
